3 Outputs for release

3.1 Checklist

The OpenSAFELY documentation provides the following checklist to consult before submitting a review request.

Do your results adhere to the OpenSAFELY permitted study results policy
Are all of the outputs of the allowed file types?
Have you redacted any low counts?
Have you rounded any counts (including counts underlying rates)?
Have you supplied underlying counts for all of your results?
Are all of the outputs clearly described? Have you provided all of the context needed to review each output in isolation? Have you described the disclosure controls you have applied to each output?
If you are requesting the release of log files, are you sure they need to be released?
Are all of the requested files below the maximum file size?

3.2 Redaction and rounding

For up-to-date information about statistical disclosure control, please see the relevant OpenSAFELY documentation.

All outputs for release should be classified as moderately_sensitive in actions.

OpenSAFELY does not permit information relating to between 1 and less than 5 individuals to be released. Redaction functions are available from other users to help you prepare your output.

If you have to maintain “0”s in your output, please use “midpoint6” rounding, which rounds to the nearest odd multiple of 3. Otherwise, please round to the nearest 5 and redact any counts <=7.

3.2.1 Example Rounding Table

Count	Midpoint6	Round5
0	0	0
1	3	0
2	3	0
3	3	0
4	3	0
5	3	0
6	3	0
7	9	0
8	9	10
9	9	10
10	9	10
11	9	10
12	9	10
13	15	15

3.2.2 Example R code for midpoint6 rounding

roundmid_any <- function(x, to = 6) {
  # centers on (integer) midpoint of the rounding points
  x <- as.numeric(x)
  ceiling(x / to) * to - (floor(to / 2) * (x != 0))
}

3.3 Allowed file types

Only certain outputs are allowed to be released from OpenSAFELY, and these must be in specific formats. For up-to-date information about statistical disclosure control, please see the relevant OpenSAFELY documentation for up to date information. The maximum file size is 16MB, regardless of filetype.

3.3.1 Tables

Use readr::write_csv() to save .csv files that will be sent to output checkers (this is about twice as fast as utils::write.csv() and does not write row names).
```
readr::write_csv(object,
                 file = file.path("output", "mydata.csv"))
```
Make sure your .csv file is not longer than 5000 rows
Make sure that any column names are understandable for reviewers

3.3.2 Figures

Before requesting figures, consider whether it is better to request a table of the underlying aggregate data, and then plot locally.
- Code to plot figures can be found in the post-release branch of existing projects (e.g., post-covid-respiratory)
- You may wish to plot a figure within OpenSAFELY to check that it looks as expected within L4, but it is not necessary to request the release of this figure if you are then able to plot it locally.
Use .svg, .jpeg, or .png for figure outputs that will be sent to output checkers
Include a supporting .csv file with the underlying aggregated data from the figure

3.3.3 Other outputs

Other file types can be released, but do consider whether they could be released in .csv format instead. For filetypes not listed here, you may need to email OpenSAFELY directly to ask for permission to release them.
.txt files can be released and are also viewable on L4
.json files can be released, but as with tables, make sure that the attributes are easily understandable for reviewers

3.4 Releasing output

When you are ready to release your ouput, please check your outputs carefully (see the documentation for guidance) and then follow the steps below:

Ensure your outputs are marked as moderately_sensitive in your project.yaml
Log into Airlock and complete the output request. You can find examples of what Airlock looks like in another part of the OpenSAFELY documentation. You will not be able to submit a request in any way other than through Airlock.
Generic examples of outputs can be found below. If you are creating a request (particularly if you’d like feedback from others), please adapt the guidance form that can be found on the grp-EHR sharepoint and save it to your project directory so that you have a record of your request.

Below, we have some example outputs from Bristol projects, with a level of detail that our output checkers have previously found helpful. You should include information in enough detail that reviewers can understand the output without needing to refer to other documentation. Each example will contain the following information:

Filegroup: this is the filegroup that the output belongs to, which is useful if you are requesting multiple files of the same format
File location: this is the location of the file/s within your project
Context: this is a description of the output, including what it shows and how it was generated.
Column descriptions: this is a description of each column in the output.
Controls: this is a description of the disclosure controls that have been applied to the output, including any redaction or rounding that has been applied.

If you are re-requesting an output, you should include what has been updated since that last request. Additionally for re-requests, you can copy the text directly from your previous request in Airlock and then update it.

3.4.1 Example Output: Table 1

Filegroup: table 1

File location: output/table1_midpoint6.csv

Context: Patient characteristics overall and in those with a COVID-19 diagnosis.

Column descriptions 

Characteristic: Patient characteristic under consideration (e.g. Sex, Age Group)

Subcharacteristic: Patient sub characteristic under consideration (e.g. Female, 55-70)

N_people [midpoint6]: Number of people with each characteristic

(%) [midpoint6_derived]: % of total study population with characteristic

N_diagnoses [midpoint6]: Number of people with characteristic and COVID-19

(% exposed) [midpoint6_derived]: % of total study population with characteristic and COVID-19

Notes:

“midpoint6” refers to data which have had midpoint6 rounding applied directly.

“midpoint6_derived” refers to data which are derived from midpoint6 columns (e.g. subtracting two midpoint6 columns)

Controls: We rounded all counts up to nearest 6 then subtracted 3 using the roundmid_any function to obscure counts. Counts less than 6 therefore appear as ‘3’. Counts of zero are maintained and considered structural for this output

3.4.2 Example Output: Flow Table

Filegroup: flow

File location: output/flow_round5.csv

Context: Table with numbers needed to generate a flow diagram, demonstrating how many people were removed from the dataset due to each of the inclusion/exclusion criteria and the quality assurance checks

Column descriptions 

Description: restrictive criteria being applied

N_round5: rounded total number of people remaining in the analysis

removed_round5_derived: rounded number of people removed due to criterion being applied

Controls: We rounded all counts to the nearest 5 and redacted any counts <=7.

3.4.3 Example Output: Cox model output

Filegroup: model output

File location: output/model_output-main-midpoint6.csv, output/model_output-subgroup-midpoint6.csv

These data provide hazard ratios and supporting information, presented in 2 CSV files covering the whole population and a subgroup. These were the main outputs of the project.

Context: Hazard ratios for incident respiratory conditions post COVID-19 in the pre-vaccination cohort. Study population includes all registered patients in England aged 18 to 110, subject to cohort specific criteria.

Column descriptions 

name: unique identifier for analysis

cohort: cohort used for the analysis

outcome: outcome used for the analysis

analysis: string to identify whether this is the ‘main’ analysis or a subgroup

error: captured error message if analysis did not run

model: string to identify whether the model adjustment

term: string to identify the term in the analysis

lnhr: log hazard ratio for the analysis

se_lnhr: standard error for the log hazard ratio for the analysis

hr: hazard ratio for the analysis

conf_low: lower confidence limit for the analysis

conf_high: higher confidence limit for the analysis

outcome_time_median: median time to outcome following exposure

strata_warning: string to identify strata variables that may cause model faults

surv_formula: survival formula for the analysis

N_total_midpoint6: rounded total number of people in the analysis

N_exposed_midpoint6: rounded total number of people with the exposure in the analysis

N_events_midpoint6: rounded total number of people with the outcome following exposure in the analysis

person_time_total_midpoint6: rounded total person time included in the analysis
